Loam Dropper Gen 2

Reengineered for rugged climbs and technical descents, the next-generation of the Loam Dropper takes our renowned reliability to new highs… and lows. Additional sizes and a lower stack height provide a modern fit for your frame, and more room to move with less saddle in your business.

FEATURES:

• More Drop = More Send: An updated saddle clamp and slimmed-down midcap shave off the equivalent of 1 Gummy Bear to 3 Oreos of stack height, making room for more travel on more bikes.
• The Long Game: A sealed dual-chamber cartridge delivers smooth, quiet actuation, while a revamped travel adjust design offers a stronger, longer-lasting setup.
• Hi Ho Silver: Silver is in, but making it shiny wasn’t easy. After rigorous testing, we landed on a hard ano process that delivers the same durability as our OG black finish.

SPECS:

• Travel Options: 125, 150, 175, 200, 225mm
• Cartridge: PNW Dual-Chamber Sealed
• Routing: Internal
• Tool-Less Travel Adjust

MEASUREMENTS:

Travel	125mm	150mm	175mm	200mm	225mm
B	Seat Collar to Center of Rails	156mm	181mm	206mm	231mm	256mm
C	Total Length	382mm	435mm	485mm	537mm	600mm
D	Min. Insertion Length	90mm	120mm	120mm	150mm	190mm
E	Full Insertion Length	226mm	254mm	279mm	306mm	344mm
*	30.9 Weight	452g	490g	524g	560g	614g
*	31.6 Weight	470g	510g	544g	580g	636g
*	34.9 Weight	516g	556g	596g	636g	700g
