Supersonic Ergo+ 45/25 SLC Aerobar

The Supersonic/Ergo+/SLC series aerobars offer industry leading ergonomics, adjustability and low weight – maximizing your comfort and speed.

The Supersonic is the top model of the Flyt series brackets – utilizing an innovative internal wedge clamp to securely hold the extension. It offers easier adjustments and a greater fit range than anything that came before it.

It is now paired with the new Ergo+ armrest that takes the popular Ergo shape and adds 40mm of length as well as a new textured cushion.

FEATURES:

• Performance: The Supersonic/Ergo+ platform is designed to give riders the freedom to find their best possible position with a huge range of independence adjustments.
• Fit Data:
  • Armrest Offset: -85mm to -17.5mm in 15mm steps
  • Armrest Width: 124mm to 290mm in 18.5mm steps (With Extensions at 100mm)
  • Armrest Stack: 58.5mm (no riser kit) to 138.5mm in 5mm increments (With aftermarket Riser Kit)
• There are 80 distinct position options achievable just by moving the armrests.  Combine that with risers and this bar offers 1440 possible configurations.  As a clip on bar it is also possible to adjust the extension width and tilt easily.
• Extension Shape: The 4525 slc extensions offer a 45deg lower and 25deg upper section. This allows the rider to choose between a low, short reach position or a high hands, stretched position for aerodynamics.
• The 4525 slc offer a 7.5mm lateral shift per side.  This allows the rider to get their hands narrower or wider without tilting the extensions so much that the shifters touch.
• The SLC extensions offer the same range of ergonomic options as the previous generation but the weight is halved. This also allows Di2 parts to be fitted inside the extension.
• All the extensions have a 22.2mm diameter in the clamping area.
• They are 400mm long and can be cut to size to suit nearly every rider.
• They are drilled for rear-exit cable routing.
• The Supersonic bracket can be paired with the Supersonic BTA mount - specifically designed to give a secure, clean and adjustable bottle cage mount for this bracket.

SPECS:

• Bracket: Supersonic
• Clamp Diameter: 31.8mm or (26.0 with Shim Kit - Shim Kit is sold separately)
• Armrest: Ergo+ / 10mm Pads
• Armrest Width: 124mm to 290mm in 18.5mm steps (with Extensions at 100mm)
• Armrest Offset: -85mm to -17.5mm in 15mm steps
• Armrest Stack: The minimum is 58.5mm and the bracket is compatible with our existing risers which add up to 138.5mm stack with (70mm of spacers added)
• Weight:
  • Bracket: 272g
  • Armrest: 217g
  • Extensions: 138g
  • Total: 627g
